C5ISR Communications Equipment and Gear

Delivering best-in-class MANET radio performance, DOCK SC4240P seamlessly scales from tactical Personal Area Network to wide-area mesh networks in any operational environment.
Features:

• 1. Low SWaP Profile with streamlined cabling & unified power reduces operator load-out
• 2. Up to 4 Watts output power (8W effective, thanks to TX Eigen Beamforming)
• 3. Up to 100 Mbps Data Throughput
• 4. Integrated Samsung S23TE (Sold Separately) – Mission-ready mobility & powerful on-board processing
• 5. ATAK – Enhanced situational awareness & mission planning
• 6. Nett Warrior – Instant access to networked devices & peripherals
• 7. Spectrum Dominance – Access LPI/LPD and Anti-Jamming capabilities for secure and protected comms in contested environments

Download the Product Brochure

Atlantic Signal's AVON Protection System Comms Cable Kit was developed for law enforcement and military clients who utilize both Atlantic Signal and Peltor brand headsets. Several attributes differentiate Atlantic Signal's Comms Cable Kit from others on the market, including the robust design, epoxy sealed circuitry housing and over molded Nexus 4 conductor plug; however, the most distinguishing characteristic lies in the manner in which the circuitry was designed for the kit. When a headset is attached to the kit - along with the headset's PTT assembly - the Comms Cable Kit automatically disables the headset's microphone, only utilizing the internal microphone of the mask when the PTT button is depressed to transmit. This feature prevents noise in the operator's ambient environment from being transmitted through his headset's boom microphone each time they transmit. This unique feature allows an operator to speak clearly and concisely with no competing noise to overcome. The Comms Cable Kit can be used with AVON Protection System's FM53, M50 and C50 masks with or without AVON's outer voice projection unit.

The VIPER II Push-to-Talk was developed by Atlantic Signal at the request of several clients looking for a push-to-talk that had the capabilities to run twin dual band radios, cross-band between radios and utilize CHAT Programs among many other requirements. The clients wanted a simple, easy to use solution out of the box with plug and play cables for various radios, ICS platforms and smartphones. Of equal importance, the clients wanted the capability to program the PTT to perform other functions. The VIPER II fulfills all these requirements and more.

FEATURES:

• Dual Net Radios: PRC163, PRC148C, TW950, SC4200 compatible
• Cross Banding Mode
• Binaural Advance Audio Mode
• Mirror PTT Switch Mode for left eye dominant users
• Vehicle ICS: VIC III & TOC-NET compatible
• Helo ICS: High Impedance, Low Impedance and Fix Wing compatible
• Belt Packs: Telephonics, David Clark and Jupiter Avionics compatible
• Masks: O2 Masks, Avon and Scott Safety compatible
• Chat Program: ES Chat and Wave Relay compatible
• Immersion rating: IP67 and IP68 (10 meters/10 hours) versions available

DIMENSIONS: 2.79' L x 2.68' W x 1.23' H

Viper 1 PTT was designed to work with the next generation Comtac V & Comtac VI headsets while allowing backward compatibility with Atlantic Signal's Warrior/Dominator cables. Atlantic Signals advanced feature programming was designed to incorporate our customer feedback and allow a product where the user can set up the PTT for their specific mission. The Viper 1 PTT is a module interface system designed for our standard commercial and military users. This PTT has two comms ports and one accessory port that can control up to 3 audio channels and can allow the user to run at max, two radios and one ICS/Phone/accessory cable.

SPECS:

• Radio Remove Volume Control Mode
• Binaural Advance Audio Mode
• Mirror PTT Switch Mode for left eye dominant users
• Vehicle ICS: VIC III & TOC-NET compatible
• Immersion Rating: IP67 and IP68 (10 meters/10 hours) versions available
• Helo ICS: High Impedance, Low Impedance and Fix Wing compatible
• Belt Packs: Telephonics, David Clark and Jupiter Avionics compatible
• Masks: O2 Masks, Avon and Scott Safety compatible
• Chat Program: ES Chat and Wave Relay compatible

DIMENSIONS: 2.79' L x 2.68' W x 1.23' H

The Comtac V Communications Headset was designed and developed over a two year period to address and overcome the unique issues associated with today's new digital and multi-band portable radios used by both law enforcement and military clientele to include cross-talk, RFI, EMI and TDMA interference. The Comtac V Communications Headset provides hearing protection while maintaining reliable comms. The Headset is wired to function in single comm stereo or multi-comm split audio working with both single and multi comm push-to-talks. This allows for cross-compatibility of all equipment regardless of single comm or dual comm builds.

SPECS:

• Dual Net Radios: PRC163, PRC148C, TW950, SC4200 compatible
• Advanced downlead connection for single, dual or multi-comm PTT use
• Helmet compatible with backband, headband and helmet rail mounted options
• Level dependent (nonlinear) hearing protection
• Advanced environmental listening
• Battery-powered (2 x AAA) for 300-350 hours of use
• Ambidextrous boom microphone
• High level of RF immunity
• Designed to eliminate cross-talk / bleed over
• Immersion Rating: IP67 (1 Meter/10 Hours)

The Below H2O Maritime Communications Headset was designed and developed for USSOCOM to withstand submersion of 10 meters for 10 hours. The Below H2O Headset integrates hearing protection and comms while meeting a maritime requirement. This maritime headset is rated to withstand submersion of 10 meters for 10 hours and comes complete with a maritime boom mic, submersible silicon inserts and a hi-noise mic.

SPECS:

• Dual Net Radios: PRC163, PRC148C, TW950, SC4200 compatible
• Advanced downlead connection for single, dual or multi-comm PTT use
• Helmet compatible with backband, headband and helmet rail mounted options
• Maritime boom mic and high noise boom mic included
• Level dependent (nonlinear) hearing protection
• Advanced environmental listening
• Battery-powered (2 x AAA) for 300-350 hours of use
• Ambidextrous boom microphone
• High level of RF immunity
• Designed to eliminate cross-talk / bleed over
• Immersion Rating: IP68 (10 Meters/10 Hours)

Introducing the next generation of 3M/Peltor Communications Headset - The COMTAC VI - an incredible, un-paralleled advancement of the #1 selling law enforcement and military communications headset brand in the world. What's different? 'ADVANCEMENT #1.' The ComTac VI has a built-in wireless intercom. Imagine being connected to your portable radio(s) and hopping into a boat, vehicle or HELO and not having to either unplug from your PTT/radio or use an add-on cable to connect to the asset's intercom! And, if your asset isn't equipped with an intercom, you don't need to go to the added expense and aggravation of wiring and mounting a permanent or portable intercom into your asset - its now built right into your headset!

FEATURES:

• Dual Net Radios: PRC163, PRC148C, TW950, SC4200 compatible
• Advanced downlead connection for single, dual or multi-comm PTT use
• Helmet compatible with backband, headband and helmet rail mounted options
• Level dependent (nonlinear) hearing protection
• Advanced environmental listening
• Battery-powered (2 x AAA) for 30-50 hours of use
• NIB Data: Frequency 915 MHZ w/ DTMA protocol
• High level of RF immunity
• Designed to eliminate cross-talk / bleed over
• Immersion Rating: IP67 (1 Meter/10 Hours)

The Invictus Single Comm Push-to-Talk was designed to provide a compact, ergonomic single comm option. The Invictus Single Comm Push-to-Talk was built to work with all radios in the market place and has been tested for Cross-Talk, RFI and EMI. The system is 100% sealed from dirt and offers the user a shrouded switch with a positive feel.

SPECS:

• Dual Net Radios: PRC163, PRC148C, TW950, SC4200 compatible
• Tested for cross-talk, RFI and EMI
• Designed to ergonomically fit in the palm of the user's hand.
• Configurable for all military and commercial radios
• Powered by radio
• Immersion rating: IP67 and IP68 (10 meters/10 hours) versions available
• Shrouded PTT switches
• Removable/rotatable MOLLE Clips
• Reversible for left-handed shooters

DIMENSIONS: 3.00' L x 1.94' W x 0.98' H

The Invictus Dual Comm Push-to-Talk was designed to provide a compact ergonomic dual comm option. The Invictus Dual Comm Push-to-Talk was built to work with all radios in the market place and has been tested for Cross-Talk, RFI and EMI. The system is 100% sealed from dirt and offers the user a shrouded switch with a positive feel. SPECS:

• Dual Net Radios: PRC163, PRC148C, TW950, SC4200 compatible
• Tested for cross-talk, RFI and EMI
• Designed to ergonomically fit in the palm of the user's hand.
• Configurable for all military and commercial radios
• Powered by radio
• Immersion rating: IP67 and IP68 (10 meters/10 hours) versions available
• Shrouded PTT switches
• Removable/rotatable MOLLE Clips
• Reversible for left-handed shooters

DIMENSIONS: 3.25' L x 2.37' W x 1.14' H

Comtac V Headset (Coyote) with 5c downlead providing both single comm and dual comm compatibility. Includes:

• Gel cups
• Ambidextrous hi-noise boom mic
• Helmet rail mounts
• Over-the-head transition band

Comtac VI headset (Coyote) with 5c downlead providing both single comm and dual comm compatibility. Includes:

• Gel cups
• Helmet rail mounts
• Over-the-head transition band
• NIB technology

Invictus PTT wired for Motorola APX series radio.

Invictus Dual Comm Push-to-Talk wired with twin PRC 148/152 6 pin radio connectors (18' & 30' leads).

'SF' PTT with radio remote volume control wired with APX series coiled connector.

R23 LO-VIS Kit.

Together with the Quad Radio Router, the Tracking Antenna System provides an encrypted digital data link to UAVs, helicopters, planes, ships and boats. The Tracking System transmits real time command and control digital video and VoIP over 100mi. Being a component of the MANET, the Tracking System acts as an extension to the existing network and allows for greater distances.

The Man Portable Unit 3 is a compact radio designed for installation or user worn applications, and available in single or dual radio modules.

The Man Portable Unit 4 brings the Wave Relay® Mobile Ad Hoc Network (MANET) capability directly to the dismounted user. Seamless Layer-2 Ethernet connectivity facilitates plug-and-play operation of cameras, video encoders, IP sensors, and other devices. In addition, the MPU4 is the smallest, lightest and most portable wireless MANET solution from the Wave Relay® product family. The MPU4 is compatible with PC-148/152 batteries, providing up to 14 hours of run-time. The MPU4 connects to Android™ phones and tablets through a high speed secure cable which also powers the device from the PC-148/152 battery. Inserted into a ruggedized case, the Android™ device and Wave Relay® MPU4 provide a light weight, field ready capability for everyday use.

The Quad Radio Router includes four customizable radio interfaces, and five 10/100 Mbps Ethernet ports that are IP67 rated and designed for outdoor use. An integrated NATO Audio 6-pin U-283/U connector enables standard push-to-talk headsets and speaker boxes to be connected to the system. Two RS-232 serial ports are available that enable serial-over-Ethernet connectivity. The Quad Radio Router can be vehicle mounted for mobile deployments, mast mounted to cover large geographic areas, and/or paired with a tracking antenna system to provide long-range, air-to-ground connectivity. It seamlessly peers to man portable Wave Relay® devices.

The most advanced, most scalable, and most efficient Mobile Ad Hoc Networking (MANET) radio in the world. Built to create powerful, secure networks anywhere, the MPU5 unites all your critical data sources in real-time Ð giving you and your team the confidence to make difficult decisions in the heat of the moment. Data, video, voice, and a fully integrated AndroidTM computer system makes the MPU5 the world's first Smart Radio.

FEATURES:

• Reliable connectivity when your team needs it most
• Built-in Android™ Operating System for mobile computing
• Runs TAK situational awareness suite
• Intelligent RoIP tethering to legacy LMRs
• Superior voice capability using G.711 audio CODEC
• HD video streaming, encoding & decoding

Wave Relay® Gen4 single radio router (board only) with 20-pin snap able interface. Includes interface board. Ordering options:

• 02: 907 - 922 MHz (27dBm/500mW)
• 03: 2312 - 2507 MHz (28dBm/600mW)
• 04: 2412 - 2462 MHz (28dBm/600mW)
• 09: 5180 - 5320, 5500 - 5700, 5745 Ð 5825 MHz (28bBm/600mW)
• 12: 2312 - 2507 MHz (33dBm/2 W)
• 13: 1350 - 1390 MHz (25dBm/1 W)
• 15: 4400 - 4800 MHz (25dBm/320mW)
• 16: 4800 - 4985 MHz (26dBm/400mW)
